Encoders and stream processing are crucial in a headend system
We understand this, and we have you covered
AW9300/AW9300E Encoder+
The Anywave AW9300/AW9300E ATSC 3.0 Encoders / Signaling Servers integrate a robust encoding system in a flexible architecture that encapsulates and sends ROUTE / MMTP. With the addition of Anywave’s new ATSC 3.0 Exciter and ATSC 3.0 Gateway, these powerful platforms provide a complete ATSC 3.0 solution to meet all of the Broadcaster’s NextgenTV needs. With options on the exciter and gateway for built-in tuners and MUX add/drop capability, this platform is the perfect solution for lighthouse arrangements with LPTV and Translators. The Anywave AW9300 Encoder+ Series provides a professional grade ATSC 3.0 / MPEG-2 TS encoder that encodes UHD1 (2160p) video as well as multiple HD/FHD videos with TS, ROUTE or MMTP streams or DASH/MPU output. These encoders also encode MPEG-2, AVC and HEVC (SD, HD and UHD @60P) video and Dolby Digital, Dolby AC-4 and MPEG-H audio.
Download a datasheet for our Encoder+ AW9300/AW9300E here
Download a brochure of our complete ATSC 3.0 signal chain here
- Easily implement and operate new ATSC 3.0 services in a variety of network configurations
- ATSC 1.0 (MPEG-2 and AVC, plus AC-3 audio) compatible – use for ATSC 1.0 now, ATSC 3.0 later
- Flexible architecture allows Broadcasters to implement studio / transmitter integrated or split architectures
- Statistical Multiplexing
- Multi-format output support - ROUTE/MMTP (with ESG), WebDAV, MPEG-2 TS (with PSIP)
- Supports closed caption (ATSC 3.0: IMSC1, MPEG-2 TS: CEA-708)
- Supported Codecs include MPEG-2 video, AVC, HEVC (up to single UHD @60p, four FHD @ 60p or
eight HD/SD), and Dolby Digital (AC-3), AC-4, AAC, MPEG-H 3D Audio - HDR, WCG Support (ATSC 3.0 only) Dolby Vision and 3D-LUT (9300E only)
- Input options - 12G-SDI/Quad 3G-SDI, 4x3G-SDI, 8xHD-SDI/SD-SDI, TS over IP
- ROUTE delivery of MPEG DASH Segments
- MMTP delivery of MPU Segments
- ROUTE delivery of Electronic Service Guide (ESG)
- ROUTE delivery of Emergency Alert Information
- Hot-swappable Redundant Power Supply
- 1RU 19-inch rack mountable type
- Enhanced Signaling Server Features (ATSC3.0) - LLS/SLS Generation, ESG Metadata Processing, NRT delivery, LLS/SLS signing
D-Series Encoders (D4 and D12)
The Anywave D-series MPEG-2/H.264 HD/SD Encoders are professional audio & video encoding platforms with powerful functionality. The D-series Encoders come equipped with either 4 HD-SDI or CVBS inputs (D4 version) or 12 HD-SDI inputs (D12 version), supporting MPEG-2 and H.264 video encoding and MPEG-1 Audio layer 2, LC-AAC and HE-AAC audio encoding. The encoded programs will output through ASI and IP ports in MPTS or SPTS.
Capabilities of the D-Series Encoder include:
- Supports up to 12 HD-SDI inputs with MPEG2 & MPEG4 AVC/H.264 Encoding
- MPEG1 Layer II, MPEG2-AAC, MPEG4-AAC, Dolby Digital AC3 (2.0) encoding, AC3 (2.0/5.1) pass through
- Supports up to 12 channel CC (close caption) inputs, EIA608/EIA708
- Supports up to 32 IP inputs (DATA1 port) over UDP and RTP
- Supports 1MPTS and up to 12 SPTS IP (DATA2 and DATA3 ports) outputs over UDP, RTP/RTSP
- Supports ASI output as a mirror of MPTS (optional)
- Supports PID remapping/ accurate PCR adjusting PSIP editing and insertion
- Control via web management, with easy updates via web interface
- Dual Power Supply (D4 only)
- IP null packet filter
- Supports VBR/CBR video encoding
Download a datasheet for our D-Series Encoder here
Stream Processing
In addition to encoding, and as part of an end-to-end solution, Anywave offers multiplexing, source conversion, and SI stream processing.
The Anywave Multi-Stream Processor is a Swiss Army Knife for DTV transmission. We are prepared for most DTV headend requirements.
Capabilities of the Multi-Stream Processor include:
- Static and Dynamic PSIP insertion
- EPG data ingest
- Multiplexing and program cherry picking
- CVBS to SDI conversion
- EAS signal and trigger processing
Download a datasheet for our Multi-Stream Processor here
